Residential Batteries
T-BAT-SYS-HV-R2.5
-
5.1 kWh-33.2 kWh
Built with a Safe LFP battery, it offers an impressive cycle life of over 6000 times and can be expanded from 5 kWh to 33 kWh per string. With a maximum charging and discharging current of 50A, this battery ensures long-lasting power storage for use.
Product Advantage
This T-BAT-SYS-HV-R2.5 is crafted with safety in mind, using non-toxic materials and rigorous testing for peace of mind. Its rack design allows for easy and fast installation by a single person, while offering a flexible and convenient energy solution for various applications.
Assured Reliability
LiFePO4 battery cell (50Ah)
No toxic heavy metals or caustic materials
High Performance
Max. 50A charging / discharging current
Cycle life > 6000 times
Reliability
Cycle life > 6000 times
Extendable from 5kWh to 33kWh per stack
Smart Management
Remote fault diagnosis, upgrade and maintenance
Product Parameters
-
T-BAT-SYS-HV-R2.5-
SYSTEM PARAMETERS
System capacity 2 ~ 13 Batteries Voltage range 89.6 ~ 759.2 V Max charge / discharge current 50 A
Protection class IP20 -
BATTERY MODULE
Battery type Li-ion (LFP) Nominal voltage 51.2 V Operating voltage 44.8 ~ 58.4 V Nominal power 1.2 kW Weight 28 kg Dimensions (L × W × H) 442 × 391 × 130 mm
-
BMS
Model TBMS-MCR0800 Dimensions (L × W × H) 442 × 391 × 130 mm Weight 8 kg
-
Data Download
-
Datasheet
-
User Manual
-
Quick Installation Guide
-
Declaration
-
File nameLanguageFormatSizeLast updateddownload
