Single Phase Inverter

X1-BOOST G3

  • 3kW / 3.3kW / 3.6kW / 4.2kW / 4.6kW / 5kW / 5.5kW / 6kW

Designed for home solar systems, the SolaX X1-BOOST G3 is easy to install and has a built-in export control that both simplifies installation and ensures compliance with local grid requirements.


Product Advantage

The X1-BOOST G3 supports 150% PV oversizing, 14A input per string, and a maximum PV input voltage of 600V.  Designed for harsh environments, it operates across -25°C to +60°C and includes safety features like over-temperature protection.

Contact Us

Superior Performance

  • 150% oversizing and 110% overloading

  • DC input 14A per string

User Friendly

  • 24H monitoring and maintenance (Optional)

  • Easy to install and set up

Safety Reliability

  • AC/DC built-in Type III SPD (Optional)

  • Over-temperature protection

  • Export control function integrated

Product Parameters

  • X1-3.0-T-D(L) / X1-3.0-T-N(L)
  • X1-3.3-T-D(L) / X1-3.3-T-N(L)
  • X1-3.6-T-D(L) / X1-3.6-T-N(L)
  • X1-4.2-T-D(L) / X1-4.2-T-N(L)
  • X1-4.6-T-D(L) / X1-4.6-T-N(L)
  • X1-5.0-T-D(L) / X1-5.0-T-N(L)
  • X1-5.5K-T-D(L) / X1-5.5K-T-N(L)
  • X1-6.0K-T-D(L) / X1-6.0K-T-N(L)
  • X1-3.0-T-D(L) / X1-3.0-T-N(L)
    • DC INPUT
      Max. PV array input power [Wp]4500
      MPP tracker voltage range [V]70 ~ 580
      No. of MPP trackers / Strings per MPP tracker2/1


    • AC OUTPUT
      Rated AC output power [W]3000
      Nominal AC voltage/ AC voltage range [V]

      220/230/240; 180~280


    • GENERAL
      Ingress protectionIP66
      Dimensions (W /H / D)[mm]

      341.5 × 430 × 143

      Net Weight[kg]13.5


  • X1-3.3-T-D(L) / X1-3.3-T-N(L)
    • DC INPUT
      Max. PV array input power [Wp]4950
      MPP tracker voltage range [V]70 ~ 580
      No. of MPP trackers / Strings per MPP tracker2/1


    • AC OUTPUT
      Rated AC output power [W]3300
      Nominal AC voltage/ AC voltage range [V]

      220/230/240; 180~280



    • GENERAL
      Ingress protectionIP66
      Dimensions (W /H / D)[mm]

      341.5 × 430 × 143

      Net Weight[kg]13.5



  • X1-3.6-T-D(L) / X1-3.6-T-N(L)
    • DC INPUT
      Max. PV array input power [Wp]5400
      MPP tracker voltage range [V]70 ~ 580
      No. of MPP trackers / Strings per MPP tracker2/1


    • AC OUTPUT
      Rated AC output power [W]3680
      Nominal AC voltage/ AC voltage range [V]

      220/230/240; 180~280



    • GENERAL
      Ingress protectionIP66
      Dimensions (W /H / D)[mm]

      341.5 × 430 × 143

      Net Weight[kg]13.5



  • X1-4.2-T-D(L) / X1-4.2-T-N(L)
    • DC INPUT
      Max. PV array input power [Wp]6300
      MPP tracker voltage range [V]70 ~ 580
      No. of MPP trackers / Strings per MPP tracker2/1


    • AC OUTPUT
      Rated AC output power [W]4200
      Nominal AC voltage/ AC voltage range [V]

      220/230/240; 180~280



    • GENERAL
      Ingress protectionIP66
      Dimensions (W /H / D)[mm]

      341.5 × 430 × 143

      Net Weight[kg]15



  • X1-4.6-T-D(L) / X1-4.6-T-N(L)
    • DC INPUT
      Max. PV array input power [Wp]6900
      MPP tracker voltage range [V]70 ~ 580
      No. of MPP trackers / Strings per MPP tracker2/1


    • AC OUTPUT
      Rated AC output power [W]4600
      Nominal AC voltage/ AC voltage range [V]

      220/230/240; 180~280



    • GENERAL
      Ingress protectionIP66
      Dimensions (W /H / D)[mm]

      341.5 × 430 × 143

      Net Weight[kg]15



  • X1-5.0-T-D(L) / X1-5.0-T-N(L)
    • DC INPUT
      Max. PV array input power [Wp]7500
      MPP tracker voltage range [V]70 ~ 580
      No. of MPP trackers / Strings per MPP tracker2/1


    • AC OUTPUT
      Rated AC output power [W]5000
      Nominal AC voltage/ AC voltage range [V]

      220/230/240; 180~280



    • GENERAL
      Ingress protectionIP66
      Dimensions (W /H / D)[mm]

      341.5 × 430 × 143

      Net Weight[kg]15



  • X1-5.5K-T-D(L) / X1-5.5K-T-N(L)
    • DC INPUT
      Max. PV array input power [Wp]8250
      MPP tracker voltage range [V]70 ~ 580
      No. of MPP trackers / Strings per MPP tracker2/1


    • AC OUTPUT
      Rated AC output power [W]5500
      Nominal AC voltage/ AC voltage range [V]

      220/230/240; 180~280



    • GENERAL
      Ingress protectionIP66
      Dimensions (W /H / D)[mm]

      341.5 × 430 × 143

      Net Weight[kg]15



  • X1-6.0K-T-D(L) / X1-6.0K-T-N(L)
    • DC INPUT
      Max. PV array input power [Wp]9000
      MPP tracker voltage range [V]70 ~ 580
      No. of MPP trackers / Strings per MPP tracker2/1


    • AC OUTPUT
      Rated AC output power [W]6000
      Nominal AC voltage/ AC voltage range [V]

      220/230/240; 180~280



    • GENERAL
      Ingress protectionIP66
      Dimensions (W /H / D)[mm]

      341.5 × 430 × 143

      Net Weight[kg]15
